Product Introduction
The GE CR306G004 is an industrial motor starter or contactor assembly from the GE CR306 series. It is designed to safely start, stop, and protect AC induction motors, integrating power switching and overload protection into a single, reliable unit.

Request Quote
Category:

Description

GE CR306G004

Technical Specifications

  • Product Type: Motor Starter / Contactor.
  • Series: GE CR306.
  • Horsepower Rating: Sized for specific motor HP/kW ratings.
  • Voltage Rating: Rated for standard industrial AC voltages (e.g., 600VAC).

Functional Features

  • Power Switching: High-capacity contacts for motor inrush and running currents.
  • Overload Protection: Integrated thermal or electronic overload relay to prevent motor burnout.
  • Auxiliary Contacts: Provides interlocking and status feedback to control circuits.

Application Scenarios

  • Industrial Motors: Pumps, fans, compressors, and conveyors.
  • Motor Control Centers (MCC): Individual motor bucket installation.

Performance Parameters

  • Contact Life: High electrical and mechanical endurance ratings.
  • Overload Trip Class: Configurable trip class for motor starting characteristics.

Material Composition

  • Contacts: Silver alloy for low resistance and arc resistance.
  • Enclosure: NEMA-rated enclosure for environmental protection.

Structural Characteristics

  • Design: Compact, modular design for space-efficient panel layout.
  • Wiring: Pre-wired or field-wired terminal options.

Working Principle
The contactor coil energizes to close the main power contacts, applying voltage to the motor. The overload relay continuously monitors motor current; if an overcurrent condition persists beyond the trip curve, it opens the control circuit to de-energize the contactor.

Installation Requirements

  • Size the starter correctly based on motor Full Load Amps (FLA).
  • Set the overload relay to the motor’s nameplate FLA.
