GE DS200CPCAG1A
Technical Specifications
- Manufacturer: General Electric (GE)
- Series: Mark V / DS200 Series
- Product Type: Control Processor Board
- Functional Acronym: CPC
Functional Features
- Central Processing: Executes turbine speed, load, and temperature control logic.
- System Coordination: Manages data flow between I/O boards and operator interfaces.
- Redundancy Support: Designed to operate in simplex or TMR (Triple Modular Redundant) configurations.
Application Scenarios
- Gas Turbines: Primary control for combustion and exhaust systems.
- Steam Turbines: Valve positioning and extraction control.
Performance Parameters
- Scan Time: Fast deterministic scan rates for real-time control.
- Reliability: Fault-tolerant design for continuous power generation.
Material Composition
Industrial-grade PCB with high-reliability microprocessors and memory modules.
Structural Characteristics
- Form Factor: Standard Mark V processor board.
- Indicators: Front-panel LEDs for run, fault, and communication status.
Working Principle
Continuously reads field inputs, executes the loaded control logic, and outputs commands to actuators while synchronizing with redundant processors to ensure safe operation.
Installation Requirements
- Install in the designated processor slot in the Mark V rack.
- Ensure proper backplane termination.
Usage Precautions
- Never remove while the system is powered on.
- Verify firmware compatibility before replacement.
