Description
GE DS200DTBAG1AAA
Technical Specifications
- Part Number: DS200DTBAG1AAA
- Type: Digital Terminal Board
- Connections: Screw terminal or spring clamp
- Compatibility: DS200 digital I/O cards
Functional Features
- Field Wiring Interface: Provides accessible termination points.
- Signal Routing: Routes field signals to I/O cards.
- Labeling: Clear terminal identification.
Application Scenarios
Control panel field wiring, I/O expansion interfaces.
Performance Parameters
- Current Rating: Rated for control circuit currents.
- Voltage Rating: Suitable for control voltages.
Material Composition
High-quality terminal blocks, PCB traces, and mounting hardware.
Structural Characteristics
Standard DS200 form factor with labeled terminals.
Working Principle
Provides passive signal routing between field wiring and I/O cards with proper isolation and protection.
Installation Requirements
- Wire according to terminal diagram.
- Torque terminals to specification.
- Verify wire gauge compatibility.
Usage Precautions
- Do not exceed terminal current ratings.
- Ensure proper wire stripping length.
- Verify connections before energizing.
