Description
GE DS200SHVIG1B
Technical Specifications
- Part Number: DS200SHVIG1B
- Series: DS200
- Function: High-Voltage Sensing / Interface
- Voltage Rating: Rated for high-voltage industrial applications
Functional Features
- High-Voltage Isolation: Provides safe galvanic isolation from high-voltage circuits.
- Signal Scaling: Steps down high voltages to measurable levels.
- Protection: Includes overvoltage and transient protection.
Application Scenarios
Power conversion systems, high-voltage motor drives, and energy storage systems.
Performance Parameters
- Isolation Voltage: High dielectric strength for safety.
- Measurement Accuracy: Precise high-voltage sensing.
Material Composition
High-voltage rated components, isolation transformers, and industrial PCB.
Structural Characteristics
Designed with adequate creepage and clearance distances for high-voltage safety.
Working Principle
Uses resistive dividers or isolation transformers to scale high-voltage signals to safe levels for low-voltage control electronics.
Installation Requirements
- Ensure adequate clearance from grounded surfaces.
- Use properly rated high-voltage cables.
- Verify isolation integrity before energizing.
Usage Precautions
- HIGH VOLTAGE HAZARD: Only qualified personnel should handle this board.
- Verify all high-voltage connections are secure and properly insulated.
- Follow lockout/tagout procedures before servicing.
