Description
GE DS200TCCBG1ANE
Technical Specifications
- Part Number: DS200TCCBG1ANE
- Manufacturer: General Electric (GE)
- Product Series: Mark V / DS200
- Board Type: Drive / Turbine Control Board
Functional Features
- Real-Time Control: Executes complex control loops for turbine speed and load management.
- I/O Interface: Interfaces with analog and discrete I/O boards for field device monitoring.
- System Diagnostics: Continuously monitors internal health and reports faults to the master controller.
Application Scenarios
Power generation plants, oil and gas processing, and heavy industrial manufacturing utilizing GE Speedtronic control systems.
Performance Parameters
- Reliability: High Mean Time Between Failures (MTBF) for mission-critical applications.
- Latency: Ultra-low latency for deterministic control response.
Material Composition
High-Tg printed circuit boards, aerospace-grade electronic components, and protective conformal coatings.
Structural Characteristics
Standard DS200 board dimensions with precision edge connectors and front-panel status LEDs.
Working Principle
Receives conditioned sensor inputs, processes them through embedded control algorithms, and generates output signals to regulate fuel valves, steam valves, and other actuators.
Installation Requirements
- Install only in designated control slots within the Mark V chassis.
- Ensure all ribbon cables and backplane connections are secure.
- Verify proper power supply voltages before applying power.
Usage Precautions
- Handle with extreme care to avoid physical damage to components.
- Adhere strictly to ESD handling procedures.
- Do not attempt to repair internal components; replace the entire board if faulty.
