Description
GE DS200TCCBG8B
Technical Specifications:
- Brand: General Electric (GE)
- Model: DS200TCCBG8B
- Product Type: Turbine Control Core Board
- System Platform: GE Mark V
Functional Features:
- TMR Logic Execution: Processes inputs from three redundant cores to determine safe and accurate turbine states.
- I/O Management: Coordinates data flow between terminal boards, I/O packs, and the main processor.
- Safety Trip Logic: Independently executes emergency shutdown sequences when critical parameters are breached.
Application Scenarios:
Legacy GE Frame 5, 6, and 7 gas and steam turbine control systems.
Performance Parameters:
Deterministic scan times ensuring that protective trips occur within milliseconds of a fault detection.
Material Composition:
Industrial-grade PCB with high-density surface-mount components and specialized turbine-control ASICs.
Structural Characteristics:
Standard Mark V board size with multiple ribbon cable connectors and discrete I/O connections.
Working Principle:
Receives digitized sensor data, compares it against safety setpoints, and outputs control signals to fuel valves, IGVs, and other actuators based on the TMR voting logic.
Installation Requirements:
Align carefully with the Mark V backplane. Ensure all ribbon cables are seated correctly and locking clips are engaged.
Precautions for Use:
Verify board revision compatibility with the rest of the Mark V system. Never remove or insert while the system is energized.
