Description
GE DS200TCEAG1B
Technical Specifications:
- Brand: General Electric (GE)
- Model: DS200TCEAG1B
- Product Type: Drive Control / Regulator Board
- Application: AC/DC Motor Drives
Functional Features:
- Motor Control: Executes advanced vector control or V/Hz algorithms for precise speed and torque regulation.
- Feedback Processing: Handles encoder, resolver, and tachometer signals for closed-loop control.
- Protection: Monitors for overcurrent, ground fault, and overtemperature conditions to protect the drive and motor.
Application Scenarios:
Essential in rolling mills, extruders, hoists, and marine propulsion applications requiring precise motor control.
Performance Parameters:
- Response Time: Microsecond-level current loop updates for dynamic motor response.
- Resolution: High-resolution feedback processing for smooth low-speed operation.
Material Composition:
Precision analog components, low-noise operational amplifiers, and high-speed digital signal processors.
Structural Characteristics:
Compact board with shielded input connectors, adjustment potentiometers, and test points for oscilloscope monitoring.
Working Principle:
Reads motor feedback signals, compares them to reference values, and adjusts PWM switching patterns to maintain desired motor performance under varying loads.
Installation Requirements:
Ensure all feedback cables are shielded and grounded properly. Route signal cables away from high-power motor leads to prevent EMI.
Usage Precautions:
Never adjust tuning potentiometers without proper instrumentation. Verify motor parameters match the board configuration before commissioning.
