Description
GE DS200TCQCG1BFE
Technical Specifications
- Product Line: GE Speedtronic Mark V.
- Part Number: DS200TCQCG1BFE.
- Board Type: Turbine Control / Signal Conditioning Board.
- Suffix Code: BFE (Indicates specific hardware revision or feature set).
Functional Features
- Turbine Parameter Monitoring: Processes signals for temperature, pressure, and speed.
- Fault Tolerance: Designed to integrate with Triple Modular Redundancy (TMR) architectures.
- Signal Conditioning: Filters and amplifies raw sensor data for the main processor.
- Relay Outputs: Controls external actuators and safety valves.
Application Scenarios
Exclusively used in power generation plants, oil and gas compressor stations, and industrial prime mover applications.
Performance Parameters
- Processing Speed: High-speed data acquisition for real-time turbine protection.
- Reliability: MTBF (Mean Time Between Failures) rated for continuous power plant operation.
- Environmental Tolerance: Withstands high temperatures and EMI in turbine enclosures.
Material Composition
Industrial-grade PCB with conformal coating to protect against moisture, sulfur, and conductive dust. Gold-plated backplane connectors for reliable signal transmission.
Structural Characteristics
Standard Mark V board form factor with front panel test points, status LEDs, and precision edge connectors for rack integration.
Working Principle
Acquires analog signals from turbine sensors, conditions them, and routes the data to the central Mark V core processor via the backplane to execute safety and control logic.
Installation Requirements
Must be installed in an active Mark V control rack. Handle by the edges to avoid damaging backplane pins.
Usage Precautions
Never hot-swap this board. Ensure the turbine control system is properly grounded. Verify configuration jumpers before powering up.
