GE DS200TCQCG1BJG
Technical Specifications
- Product Line: GE Speedtronic Mark V.
- Part Number: DS200TCQCG1BJG.
- Board Type: Turbine Control / Signal Conditioning Board.
- Suffix: BJG (Specific revision and feature set).
Functional Features
- Precision Signal Conditioning: Processes turbine sensor signals with high accuracy.
- TMR Compatibility: Designed for Triple Modular Redundancy safety systems.
- Actuator Interface: Controls and monitors turbine control valves.
- Diagnostics: Comprehensive onboard fault detection and reporting.
Application Scenarios
Critical component in gas and steam turbine control systems for power generation and industrial cogeneration.
Performance Parameters
- Signal Accuracy: High-resolution analog processing.
- Safety Integrity: SIL-rated safety functions.
- Environmental Rating: Withstands turbine enclosure conditions.
Material Composition
Multi-layer PCB with conformal coating, precision analog components, and gold-plated backplane connectors.
Structural Characteristics
Standard Mark V board with front panel test points, status LEDs, and precision edge connector.
Working Principle
Conditions sensor signals, executes control logic, and interfaces with the Mark V core processor to manage turbine operation safely and efficiently.
Installation Requirements
Install in designated Mark V rack slot. Ensure proper alignment and secure mounting.
Usage Precautions
Never hot-swap. Verify exact part number and suffix. Follow all turbine safety and lockout/tagout procedures.
