Description
GE DS200UCIAG1A
Technical Specifications
- Part Number: DS200UCIAG1A
- Protocol Support: Serial/Ethernet communication
- Ports: Multiple communication interfaces
- Isolation: Galvanic isolation on all ports
Functional Features
- Data Gateway: Translates internal control data to standard protocols.
- Multi-Port Connectivity: Supports simultaneous connections.
- Protocol Conversion: Bridges proprietary and open standards.
Application Scenarios
SCADA integration, HMI connectivity, and remote monitoring systems.
Performance Parameters
- Baud Rate: Configurable serial speeds.
- Network Speed: Ethernet 10/100 Mbps.
Material Composition
Network transformers, serial transceivers, and communication processors.
Structural Characteristics
Standard card with RJ45/DB9 connectors and link/activity LEDs.
Working Principle
The board polls internal control data and packages it into standard protocol frames for transmission to external systems.
Installation Requirements
- Use Category 5e or better Ethernet cables.
- Configure IP addresses and serial parameters.
- Ensure proper network segmentation.
Usage Precautions
- Do not connect to unisolated networks.
- Verify protocol settings match external devices.
- Secure communication ports against unauthorized access.
