Description
GE DS2020FECNRP010A
Technical Specifications
- Part Number: DS2020FECNRP010A
- Manufacturer: General Electric
- Series: Mark V Speedtronic
- Product Type: Field Exciter Board
- Functional Acronym: FECN
- Field Supply Version: Non-Plugging Field Supply
- Line Fuse Rating: 30 A
- Excitation Capacity: Up to 24 Amps
- Excitation Type: NRX (Non-Reversing Field Supply)
- Shunt Rating: 10 Amp
- Input: 1-Phase 600 VAC
- Output: Field excitation DC
Key Features
- Non-plugging field supply for safe generator operation
- Up to 24A excitation capacity
- 30A line fuse protection
- NRX non-reversing field supply type
- 10 amp shunt rating
- 1-phase 600VAC input capability
- Controlled DC output for field winding excitation
- Designed for Mark V Speedtronic systems
Application Scenarios Synchronous generator excitation systems, power plant turbine-generator sets, industrial motor excitation, utility power generation, synchronous machine field control
Performance Parameters
- Line Fuse Rating: 30 A
- Excitation Capacity: Up to 24 Amps
- Shunt Rating: 10 Amp
- Input Voltage: 1-Phase 600 VAC
- Field Supply Type: NRX (Non-Reversing)
Material Composition High-quality industrial-grade printed circuit board with power electronic components. The board includes rectifiers, filtering components, and control circuitry designed for reliable field excitation in power generation environments.
