Description
GE DS3800H0SA1E1D
Technical Specifications:
- Brand: General Electric (GE)
- Model: DS3800H0SA1E1D
- Product Type: Signal Conditioning Board
- System Platform: Series 90-30 / Mark IV
Functional Features:
- Signal Scaling: Converts raw sensor outputs (e.g., mV, V, mA) to standardized digital engineering units.
- Filtering: Applies hardware and software filters to eliminate electrical noise and signal ripple.
- Isolation: Protects the control system from ground loops and transient voltage spikes.
Application Scenarios:
Deployed in process control, temperature monitoring, and vibration analysis applications.
Performance Parameters:
- Accuracy: High-precision analog-to-digital conversion for reliable process control.
- Stability: Temperature-compensated circuits for consistent performance in varying environments.
Material Composition:
Precision operational amplifiers, low-tolerance resistors, and isolation transformers.
Structural Characteristics:
Compact board with adjustable calibration potentiometers, test points, and standard backplane connectors.
Working Principle:
Receives raw analog signals, applies amplification and filtering, and converts them to digital values that are scaled to match the physical process variable.
Installation Requirements:
Use shielded twisted-pair cables for all analog inputs. Calibrate the board using a precision signal source after installation.
Usage Precautions:
Never apply voltages exceeding the board’s maximum rating. Handle calibration potentiometers gently to avoid misalignment.
