GE DS3800HPTN1J1H
Technical Specifications
- Manufacturer: General Electric (GE)
- Product Series: Mark IV Turbine Control System
- Board Type: Control and Regulation Board
- Compatibility: Designed specifically for Mark IV turbine control racks
Functional Features
- Turbine Regulation: Manages critical turbine parameters including speed, temperature, and pressure.
- Fault Tolerance: Built-in redundancy and fault detection mechanisms to ensure continuous operation.
- Signal Processing: Accurately processes sensor inputs to execute precise control algorithms.
Application Scenarios
Exclusively used in power generation facilities operating GE Mark IV controlled gas turbines, steam turbines, and combined cycle power plants.
Performance Parameters
- Response Time: Millisecond-level response to changing turbine operating conditions.
- Reliability: High Mean Time Between Failures (MTBF) designed for continuous 24/7 power generation.
Material Composition
Manufactured with high-grade industrial PCBs, conformal coating for environmental protection, and precision electronic components rated for extended temperature ranges.
Structural Characteristics
Standard Mark IV board form factor with rear-mounted backplane connectors and front-panel diagnostic LEDs for easy troubleshooting.
Working Principle
Receives analog and digital signals from turbine sensors, processes them through onboard logic, and outputs control signals to actuators and valves to maintain optimal turbine operating parameters.
Installation Requirements
Must be installed in a designated Mark IV control rack slot. Ensure proper backplane seating and secure front panel mounting screws.
Usage Precautions
Never remove or insert the board while the control system is powered. Follow all lockout/tagout procedures before maintenance. Handle with ESD precautions.
