GE DS3800HXMA1G1G
Technical Specifications
- Part Number: DS3800HXMA1G1G
- Series: Mark IV / Speedtronic
- Function: Analog Processing / Memory Interface
- Signal Type: Low-voltage analog signals
Functional Features
- Signal Conditioning: Scales and filters analog inputs from sensors.
- Data Storage: Interfaces with memory components for configuration or logging.
- System Communication: Transmits processed data to the main processor.
Application Scenarios
Turbine temperature monitoring, pressure sensing, and system configuration management.
Performance Parameters
- Signal Accuracy: High-precision analog-to-digital conversion.
- Noise Rejection: Excellent common-mode noise immunity.
Material Composition
Precision analog components, memory ICs, and multi-layer industrial PCB.
Structural Characteristics
Standard Mark IV board size with high-density backplane connectors.
Working Principle
Analog signals are conditioned and digitized, then transferred across the backplane to the central processing unit for control algorithm execution.
Installation Requirements
- Handle with care to avoid damaging sensitive analog components.
- Ensure proper seating in the designated chassis slot.
- Verify system configuration matches the board revision.
Usage Precautions
- Avoid exposure to strong electromagnetic fields.
- Do not apply voltages exceeding the analog input specifications.
- Maintain a clean, dry operating environment.
