Description
GE DS3800NVCD1D1C
Technical Specifications
- Part Number: DS3800NVCD1D1C
- System Compatibility: GE Mark IV Speedtronic
- Product Type: Control / I/O Processing Board
Functional Features
- Sensor Integration: Interfaces with thermocouples, RTDs, and pressure transducers for real-time turbine monitoring.
- Logic Execution: Processes safety interlocks and operational sequencing.
- Backplane Communication: Transmits processed data to the Mark IV core processors via the system backplane.
Application Scenarios
Gas and steam turbine control systems, power generation plants, and critical industrial infrastructure.
Performance Parameters
- Reliability: Extremely high Mean Time Between Failures (MTBF) for mission-critical applications.
- Scan Rate: Deterministic processing for fast turbine protection.
Material Composition
Military/aerospace-grade electronic components and multi-layer industrial PCB.
Structural Characteristics
Standard Mark IV board dimensions with precision edge connectors and front-panel status LEDs.
Working Principle
Acquires analog and discrete field signals, conditions them, and routes the digital data across the backplane for the Mark IV voting processors to evaluate and execute control actions.
Installation Requirements
- Insert into the correct designated slot in the Mark IV rack.
- Verify hardware configuration matches the turbine specification.
- Secure the board with retaining hardware.
Usage Precautions
- Never replace or service while the turbine is in operation.
- Follow strict GE Mark IV safety and ESD procedures.
- Backup system configuration prior to installation.
