Product Overview The GE DT07H-10-6PN is a miniature hermetic electronic connector from the DT series, designed for harsh environment applications requiring sealed, reliable electrical connections. These connectors are commonly used in aerospace, military, and industrial applications where environmental sealing and vibration resistance are critical. (Note: Specific GE-branded data was limited; specifications below are based on the DT series standard from the manufacturer.)

Request Quote
Category: SKU: GE DT07H-10-6PN

Description

GE DT07H-10-6PN

Technical Specifications

Parameter Specification
Brand General Electric (GE)
Series DT Series
Product Type Hermetic Jam Nut Mount Connector
Shell Style DT07H (Jam Nut Mount)
Insert Arrangement 10-6 (10 shell size, 6 pin positions)
Contact Type Pin (Male)
Contact Size Size 20 (standard for DT series)
Mounting Type Jam nut (hexagonal mounting for panel installation)
Hermetic Rating Hermetically sealed
Material Aluminum alloy shell with cadmium or nickel plating
Insulation Material High-grade polymer/rubber seals
Temperature Range -55°C to +125°C (standard DT series)
Mating Connector DT06H-10-6SN (receptacle)

Key Features

  • Hermetic Sealing: Prevents ingress of moisture, dust, and contaminants, ensuring reliable performance in harsh environments.

  • Jam Nut Mounting: Hexagonal design allows secure panel mounting with proper torque application.

  • Rugged Construction: Aluminum alloy shell with durable plating provides excellent corrosion resistance and mechanical strength.

  • High Vibration Resistance: Designed to withstand severe vibration and shock conditions typical in aerospace and industrial turbine applications.

  • Standardized Design: Compatible with MIL-spec standards for interchangeability and broad application support.

Structural Features

  • Hexagonal jam nut for wrench-tightened installation.
  • Polarized shell design prevents incorrect mating.
  • Silicone rubber seals maintain hermetic integrity under thermal cycling.
  • Gold-plated contacts ensure low contact resistance and high conductivity.

Applications

  • Aerospace and avionics systems
  • Gas turbine control systems
  • Military vehicles and equipment
  • Industrial machinery in harsh environments
  • Marine and offshore applications

Installation Requirements

  • Use proper torque specifications when tightening jam nut to avoid damage to seals.
  • Ensure panel cutout matches shell size 10 dimensions.
  • Verify proper polarization before mating connectors.
  • Apply appropriate thread sealant or lubricant as specified for the installation environment.
