Description
GE FBN36TE060RV
Technical Specifications
- Poles: 3-Pole.
- Frame Size: FBN.
- Continuous Current Rating: 60 Amps.
- Voltage Rating: 600VAC Max.
Functional Features
- Adjustable Trip (if applicable): Some FBN variants allow field-adjustable trip settings.
- Arc Chutes: Internal arc extinguishing chambers for safe fault interruption.
- Dual Rating: Suitable for both AC and DC applications (with derating).
Application Scenarios
Motor control centers, industrial heaters, large HVAC compressors, and feeder protection.
Performance Parameters
- Short Circuit Rating: High interrupting capacity for modern power systems.
- Temperature Compensation: Bimetallic elements compensate for ambient temperature variations.
- Impedance: Low contact resistance to minimize heat generation.
Material Composition
High-strength thermoset housing, arc-resistant steel chutes, and precision-wound magnetic coils.
Structural Characteristics
Standard NEMA/IEC dimensions for interchangeability. Features accessory slots for shunt trips, auxiliary switches, and alarm contacts.
Working Principle
Monitors current flow continuously. When current exceeds the thermal or magnetic threshold, the internal mechanism unlatches, separating contacts and extinguishing the resulting arc.
Installation Requirements
Ensure adequate wire sizing for 60A load. Use copper conductors unless rated for aluminum. Torque to manufacturer specifications.
Usage Precautions
Do not use as a routine disconnect switch. Inspect contacts for pitting after high-current interruptions.
