Description
GE H201TI Technical Specifications:
- Input Type: Thermocouple (J, K, T, E, R, S, B, N).
- Cold Junction Compensation: Built-in CJC for accurate measurement.
- Resolution: High-resolution temperature conversion.
- Isolation: Channel isolation for noise immunity.
Functional Features:
- Multi-Type Support: Software-selectable thermocouple type.
- Open Thermocouple Detection: Detects broken sensor wires.
- Linearization: Built-in linearization tables.
- Filtering: Configurable filtering for stable readings.
Application Scenarios:
- Furnace and oven temperature control.
- Boiler and turbine monitoring.
- Chemical reactor temperature measurement.
- Food and beverage processing.
Performance Parameters:
- Accuracy: High-accuracy temperature measurement.
- Stability: Low drift over temperature and time.
- Response Time: Fast temperature tracking.
Material Composition & Structural Characteristics:
- PCB: Precision analog components and CJC sensor.
- Terminals: Dedicated thermocouple terminals.
- Indicators: Status and fault LEDs.
Working Principle: The module measures the thermocouple voltage and adds the cold junction voltage to compensate for ambient temperature. The total voltage is converted to temperature using standard thermocouple tables.
Installation Requirements:
- Wiring: Use thermocouple extension wire.
- Polarity: Observe correct polarity.
- Grounding: Avoid ground loops.
Usage Precautions:
- Sensor Type: Ensure correct thermocouple type selection.
- Extension Wire: Use proper extension wire for the thermocouple type.
- CJC: Ensure CJC sensor is not exposed to heat sources.
