Name: GE HE700GEN200
Brand: GE
SKU: GE HE700GEN200

GE HE700GEN200

Product Overview: The HE700GEN200 is a versatile network interface module designed for the GE Fanuc Series 90-70 high-performance PLC system. This module serves as a gateway between the Series 90-70 backplane and various industrial network protocols, enabling seamless integration of the PLC into modern distributed control architectures.

Request Quote

Category: GE SKU: GE HE700GEN200

Description

GE HE700GEN200

Technical Specifications:

Network Interface: Dual Ethernet ports 10/100 Mbps with auto-negotiation
Protocols Supported: SRTP (Service Request Transport Protocol), EGD (Ethernet Global Data), Modbus TCP/IP, PROFINET IO Device
Backplane Interface: Series 90-70 VME backplane with dual-port RAM
Data Transfer Rate: Up to 10,000 words per second across the backplane
Memory: 2MB onboard RAM for network data buffering
Power Consumption: 5V DC at 1.2A from backplane
Indicators: LED status for link, activity, speed, and error conditions

Functional Features:

Simultaneous multi-protocol operation on separate Ethernet ports
Automatic device detection and configuration through network discovery
Redundant network path support with bumpless switchover
Time synchronization via SNTP (Simple Network Time Protocol)
Embedded web server for diagnostic and configuration access
Data historian buffer for 10,000 data points with timestamp
Cybersecurity features including password protection and access logging

Application Scenarios:

Large-scale manufacturing execution system (MES) integration
Power plant distributed control system (DCS) networking
Oil platform centralized monitoring with redundant communication
Smart grid substation automation and remote monitoring
Water distribution SCADA system backbone connectivity
Pharmaceutical batch control with electronic record keeping

Performance Parameters:

Network Latency: Less than 5 milliseconds for local subnet communication
Concurrent Connections: Up to 32 simultaneous client connections
Data Throughput: 1000 discrete I/O points per second per protocol
Redundancy Switchover Time: Less than 50 milliseconds

Structural Characteristics:

Dual RJ-45 front panel connectors with magnetic isolation
Standard Series 90-70 double-width module form factor
Removable media for firmware updates via USB port
Conformal coating option for corrosive atmospheres

Working Principle: The HE700GEN200 operates as a coprocessor on the Series 90-70 VME backplane. It continuously scans the PLC memory map through dual-port RAM, updating network data buffers with the latest I/O and register values. Simultaneously, it processes incoming network requests from HMI stations, SCADA servers, or other PLCs, writing the received data to the appropriate backplane memory addresses. The module’s internal processor manages all protocol stack processing, TCP/IP socket management, and data conversion, ensuring the main PLC CPU remains dedicated to control logic execution.
