GE HYDRAN M2 - Image 2

GE HYDRAN M2

Product Overview: The GE HYDRAN M2 is an advanced online dissolved gas monitoring system for power transformers. Building on the HYDRAN legacy, the M2 model incorporates enhanced measurement capabilities, improved communication options, and expanded diagnostic features. It provides comprehensive transformer condition assessment through continuous DGA monitoring with enhanced accuracy and reliability.

Request Quote
Category: SKU: GE HYDRAN M2

Description

GE HYDRAN M2

Technical Specifications:

  • Measured Gases: Hydrogen (H2), Carbon Monoxide (CO), Carbon Dioxide (CO2), Methane (CH4), Acetylene (C2H2), Ethylene (C2H4), Ethane (C2H6), Oxygen (O2), Moisture (H2O in oil)

  • Detection Technology: Photoacoustic spectroscopy with dual-beam reference

  • Measurement Range: 0-2000 ppm for each gas; 0-100% relative saturation for moisture

  • Accuracy: ±5% of reading or ±1 ppm, whichever is greater

  • Repeatability: ±2% of reading at 100 ppm

  • Oil Temperature Compensation: Automatic compensation from -30°C to +110°C

  • Ambient Operating Range: 40°C to +60°C

  • Power Supply: Universal 100-240V AC or 125-375V DC

  • Communication: Ethernet, RS-485, USB, optional Wi-Fi or cellular

Functional Features:

  • Simultaneous multi-gas analysis with no moving parts
  • Automatic calibration verification with internal reference gas
  • Transformer health index calculation based on IEEE C57.104
  • Rate-of-gas-generation trending with predictive failure analysis
  • Integration with GE Perception software for fleet management
  • Modbus TCP/IP and DNP3.0 protocol support for SCADA integration
  • Email and SMS alarm notification capability
  • Web-based user interface for remote access and configuration

Application Scenarios:

  • EHV (Extra High Voltage) transformer monitoring at 500kV substations
  • Industrial arc furnace transformer protection
  • HVDC converter transformer condition monitoring
  • Offshore platform main transformer surveillance
  • Nuclear plant safety-related transformer monitoring
  • Smart grid transformer asset management programs

Performance Parameters:

  • Measurement Cycle: Configurable from 30 minutes to 24 hours

  • Data Storage: 1 million measurement records with 5-year retention

  • Network Security: TLS 1.2 encryption, user authentication, firewall

  • Environmental Rating: IP66 with C5-M marine corrosion protection option

  • Shock and Vibration: IEC 60068-2-6 and IEC 60068-2-27 compliant

Structural Characteristics:

  • Compact wall-mount enclosure with stainless steel 316L construction
  • Touchscreen HMI with 7-inch color display
  • Internal heating system for cold climate operation
  • Modular design allowing field replacement of sensor modules
  • Oil connection via 1/2-inch NPT or BSP fittings

Working Principle: The HYDRAN M2 employs advanced photoacoustic spectroscopy with a dual-beam configuration. Infrared radiation from a broadband source passes through an optical filter wheel containing interference filters tuned to specific gas absorption wavelengths. The filtered light enters the photoacoustic cell, where gas molecules absorb the radiation and generate pressure waves. A high-sensitivity microphone detects these acoustic signals. A reference beam compensates for source intensity variations and window contamination. The system uses chemometric algorithms to resolve overlapping absorption spectra and calculate individual gas concentrations with high precision.

Installation Requirements:

  • Mount on transformer tank or adjacent wall with vibration isolation
  • Connect oil sampling lines with proper purging before operation
  • Provide Ethernet connection to local network or SCADA
  • Ensure proper grounding of enclosure to transformer ground
  • Install surge protection on power and communication lines

Usage Precautions:

  • Allow 24-hour warm-up period after initial energization
  • Perform baseline measurement comparison with laboratory DGA results
  • Set alarm thresholds based on transformer loading and age
  • Update firmware only during scheduled maintenance windows
  • Maintain backup of configuration and historical data
