Description
GE IC200CHS002 Technical Specifications
-
Carrier Style: Box-style terminal
-
Terminals: 36 barrier-style terminals (A1–A18, B1–B18)
-
Dimensions: 133.4 mm (H) × 66.8 mm (L) × 70 mm (D) — 5.25 in × 2.63 in × 2.75 in
-
Weight: 0.69 lbs (approximately 0.31 kg)
-
Voltage Rating: 0–264 VAC
-
Transient Voltage Rating: Up to 300 VAC
-
Current Rating: 2 A per point; 8 A per power/ground terminal
-
Wire Compatibility: Single wire: 0.36–2.1 mm² (AWG #22–#14); Dual wire: up to 0.86 mm² (AWG #18)
-
Terminal Torque: 0.37–0.45 lbf·ft
-
Mounting: 35 mm DIN rail (EN 50022), horizontal orientation
-
Mounting Clearance: Top/bottom: 2 in (5.1 cm); Side: 1 in (2.54 cm)
-
Operating Temperature: 40°C to +70°C
-
Power Consumption: 805 mA typical; 2.48 W
Structural Features
-
Integrated field termination — no external terminal blocks required
-
Carrier-to-carrier mating connectors for quick backplane connection without additional cables or tools
-
Easily-set keying dials to prevent incorrect module installation
-
Module latch hole for secure fastening
-
Foldable printed wiring card holder for documentation storage
-
Snap-on DIN rail mounting with optional panel mounting for high-vibration environments
Installation Requirements The DIN rail must be electrically grounded with a conductive, corrosion-resistant finish (preferably unpainted). For maximum resistance to mechanical vibration and shock, panel-mount the carrier in addition to DIN rail mounting. The carrier accommodates solid or stranded copper wire only.
