Description
GE IC200GBI001
Technical Specifications:
- Network: Genius Bus (155.5 Kbaud).
- Topology: Bus or daisy-chain.
- I/O Scanning: Supports scanning of Genius Bus I/O blocks.
- Peer-to-Peer: Supports Global Data exchange with other Genius nodes.
Functional Features:
- Legacy Integration: Bridges modern VersaMax PLCs with existing Genius Bus infrastructure.
- Deterministic Performance: Guaranteed data delivery timing for critical control applications.
- Built-in Redundancy: Supports redundant Genius Bus cabling for high-availability systems.
Application Scenarios:
- Upgrading Series 90-30/70 systems while retaining existing Genius I/O.
- Multi-PLC coordination over long distances in steel mills or automotive plants.
- Remote I/O distribution in hazardous areas using intrinsically safe Genius barriers.
Material Composition & Structural Characteristics:
- Connectors: Dual DB9 connectors for primary and redundant Genius Bus connections.
- Termination: Built-in termination resistors selectable via DIP switches or jumpers.
Working Principle: The GBI001 participates in the Genius Bus token-passing protocol. It transmits and receives data frames, scanning configured I/O blocks and exchanging global data with other nodes on the network.
Installation Requirements:
- Termination: Properly terminate both ends of the Genius Bus network.
- Addressing: Set the Genius Bus node address using hardware switches before powering up.
Usage Precautions:
- Bus Loading: Ensure the total number of nodes and cable length comply with Genius Bus specifications.
- Shielding: Use only approved Genius Bus shielded cable and maintain proper shield grounding.
