GE IC660BBA105N1
Technical Specifications
- Part Number: IC660BBA105N1
- I/O Configuration: 16 Configurable Points (Inputs or Outputs)
- Voltage Rating: 12/24V DC
- Communication: Genius Bus Protocol
Functional Features
- Point Configurability: Each point can be individually configured as an input or output via software.
- Distributed Architecture: Reduces wiring costs by locating I/O near field devices.
- Diagnostic Capabilities: Provides point-level diagnostics including short circuit and open wire detection.
- Hot Swap: Supports module replacement without powering down the bus.
Application Scenarios
Distributed manufacturing lines, material handling systems, and remote monitoring stations.
Performance Parameters
- Input Response Time: Fast digital scanning for real-time feedback.
- Output Current: Sufficient drive capability for standard industrial loads.
Material Composition
Ruggedized plastic housing with industrial-grade PCB and spring-clamp or screw terminals.
Structural Characteristics
Compact, modular block design with integrated status LEDs for each I/O point and bus communication.
Working Principle
The block communicates with the Genius Bus Controller (GBC) over a serial network, exchanging digital state data and diagnostic information continuously.
Installation Requirements
- Connect to the Genius Bus using properly terminated shielded twisted-pair cable.
- Set the bus address using the onboard rotary or DIP switches.
- Provide a stable 24V DC power supply.
Usage Precautions
- Verify bus termination is correct at both ends of the network.
- Ensure proper grounding of the bus shield.
- Configure points correctly in the PLC software before operation.
