GE IC670CHS002
Technical Specifications:
| Parameter | Specification |
|---|---|
| Product Line | Genius I/O Series |
| Component Type | I/O Terminal Block |
| Module Capacity | Mounts 2 Independent I/O Modules |
| Number of Terminals | 32 to 37 terminals depending on reference |
| Connector Type | Screw-type terminal block |
| Voltage Rating | 24VDC nominal |
| Current Rating | 2A per terminal |
| Dimensions | 105mm x 45mm x 25mm |
| Weight | Approximately 200g |
Functional Features:
- Serves as mounting base for two independent I/O modules
- Provides hot-swappable module connectivity
- Offers platform for communication connections
- Facilitates power connections distribution
- Creates user connection terminal platform
- Any GE Fanuc compatible module can connect/disconnect without system shutdown
Application Scenarios:
- Series 90-30/70 PLC backplane expansion
- Distributed I/O station construction
- Control cabinet terminal consolidation
- Field device connection points
- I/O subsystem modularization
- Flexible I/O configuration systems
Performance Parameters:
| Parameter | Value |
|---|---|
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C (typical industrial rating) |
| Protection Rating | IP20 |
| Terminal Torque | Maximum 4.5 pounds per inch |
| Humidity Range | 5% to 95% non-condensing |
Construction Characteristics:
- Box-type terminal design for secure connections
- Vibrational resistance for industrial environments
- Metal housing with corrosion-resistant coating
- DIN rail compatible mounting feet
- UL and other industry standard compliant
Installation Requirements:
- Mount on appropriate rack or DIN rail system
- Attach two compatible I/O modules simultaneously
- Tighten terminal screws to 4.5 lb-in maximum torque
- Connect Bus Interface Unit module to enable communication
- Route field wires to designated box terminals
Usage Precautions:
- Ensure module is securely screwed to prevent vibration disconnection
- Disconnect all power before major reconfiguration
- Verify terminal torque specifications during installation
- Maintain clean contact surfaces for reliable operation
- Protect from excessive moisture and contaminants
