  • Product Introduction: This is a 2-channel 24VDC sinking (NPN) digital input module for the GE 90-30 and VersaMax PLC families. It is a compact, low-cost module used for basic on/off signal acquisition from sensors, switches, and relay contacts in small-to-medium automation systems.
Request Quote
Category: SKU: GE IC670GBI002

Description

GE IC670GBI002

  • Technical Specifications:
    • Channels: 2 independent digital input channels
    • Input Type: 24VDC sinking (NPN)
    • Input Voltage: 18VDC to 30VDC (high), 0V to 5VDC (low)
    • Input Current: ~3mA per channel (sinking)
    • Response Time: 5ms ON→OFF, 10ms OFF→ON
    • Isolation: Optically isolated, 500V RMS
    • Power Consumption: ~0.5W
    • Operating Temperature: 0°C to 60°C
  • Functional Features:
    • 2 NPN input channels with LED indicators
    • Backplane-powered
    • Compact IC670 form factor (smaller than IC660)
    • Compatible with 90-30 and VersaMax PLCs
  • Application Scenarios:
    • Basic sensor interfacing
    • E-stop circuit monitoring
    • Door open/closed detection
    • Simple on/off control feedback
  • Performance Parameters:
    • Input Impedance: ~5kΩ
    • Isolation: 500V RMS
    • Bus: Genius Bus (90-30) or VersaMax backplane
  • Material Composition:
    • Housing: ABS, UL94 V-0
    • PCB: FR-4, 2-layer
    • Terminals: Screw-type, 18-22 AWG
  • Structural Features:
    • Half-width IC670 module
    • 2 red LEDs on front panel
    • DIN-rail mount
  • Working Principle:
    • NPN sensor pulls input to ground when active. Internal opto-isolator detects the voltage drop, signaling logic “1” to the CPU.
  • Installation Requirements:
    • IC693 or IC695 chassis (90-30 / VersaMax)
    • Wire NPN sensors to inputs, common to 0V
  • Usage Precautions:
    • NPN sensors only
    • Do not exceed 30VDC
    • Use shielded cable in noisy environments
