  • Product Introduction: This is a 2-channel 24VDC sourcing (PNP) digital input module for the GE 90-30 PLC platform. It is the PNP counterpart to the IC670GBI002. It provides the same compact form factor but accepts sourcing-type sensor signals, making it suitable for European and Asian sensor standards.
Request Quote
Category: SKU: GE IC670GBI002H

Description

GE IC670GBI002H

  • Technical Specifications:
    • Channels: 2 independent digital input channels
    • Input Type: 24VDC sourcing (PNP)
    • Input Voltage: 18VDC to 30VDC (high), 0V to 5VDC (low)
    • Input Current: ~3.5mA per channel (sourcing)
    • Response Time: 5ms / 10ms
    • Isolation: 500V RMS optical
    • Power: ~0.5W
    • Temperature: 0°C to 60°C
  • Functional Features:
    • 2 PNP input channels with LED status
    • Backplane-powered
    • IC670 compact form factor
    • 90-30 / VersaMax compatible
  • Application Scenarios:
    • European sensor integration
    • Compact machine I/O
    • Safety circuit monitoring
    • Small panel-mounted applications
  • Performance Parameters:
    • Input Impedance: ~7kΩ
    • Isolation: 500V RMS
    • Bus: Genius Bus
  • Material Composition:
    • Housing: UL94 V-0 ABS
    • PCB: FR-4, 2-layer
    • Terminals: Screw, 18-22 AWG
  • Structural Features:
    • Half-width IC670 module
    • 2 green LEDs
    • DIN-rail mount
  • Working Principle:
    • PNP sensor provides +24V when active. Opto-isolator detects voltage, CPU reads logic “1”.
  • Installation Requirements:
    • IC693 or IC695 chassis
    • PNP sensors: +24V to input, 0V to common
  • Usage Precautions:
    • PNP sensors only
    • Max 30VDC per channel
    • Shielded cable recommended
