  • Product Introduction: This is an 8-channel 24VDC sinking (NPN) digital input module for the GE 90-30 PLC family. It provides high-density digital input capability in a compact IC670 form factor. It is widely used in applications requiring many discrete input points in a small space, such as panel-mounted control systems and machine I/O aggregation.
Request Quote
Category: SKU: GE IC670GBI102D

Description

GE IC670GBI102D

  • Technical Specifications:
    • Channels: 8 independent digital input channels
    • Input Type: 24VDC sinking (NPN)
    • Input Voltage: 18VDC to 30VDC (high), 0V to 5VDC (low)
    • Input Current: ~3mA per channel (sinking)
    • Response Time: 5ms ON→OFF, 10ms OFF→ON
    • Isolation: 500V RMS, 2 groups of 4 channels
    • Power Consumption: ~1.2W
    • Operating Temperature: 0°C to 60°C
  • Functional Features:
    • 8 NPN input channels with individual LED indicators
    • Two isolation groups (channels 1-4 and 5-8) for mixed-signal safety
    • Backplane-powered
    • Compact IC670 form factor
    • Compatible with 90-30 and VersaMax PLCs
  • Application Scenarios:
    • High-density sensor monitoring
    • Panel-mounted machine I/O
    • Safety door and gate monitoring
    • Process control discrete input aggregation
    • Conveyor sensor arrays
  • Performance Parameters:
    • Input Impedance: ~5kΩ
    • Isolation: 500V RMS per group
    • Common Mode Rejection: >1000V
    • Bus: Genius Bus (90-30) / VersaMax backplane
    • MTBF: >150,000 hours
  • Material Composition:
    • Housing: UL94 V-0 ABS/polycarbonate blend
    • PCB: 4-layer FR-4, conformal coated
    • Terminals: Screw-type, 18-22 AWG
    • Isolation: Opto-couplers per channel group
  • Structural Features:
    • Standard IC670 module width
    • 8 red LED status indicators on front panel
    • Two isolation barrier zones
    • DIN-rail or chassis mount
  • Working Principle:
    • NPN sensors pull each input to ground when active. The opto-isolator detects the voltage change, and the CPU reads the logic state via the backplane bus. The two isolation groups allow mixing of high-voltage and low-voltage signals safely.
  • Installation Requirements:
    • Mount in IC693 or IC695 chassis
    • Wire NPN sensors: sensor output to module input, sensor ground to module common
    • Use 18-22 AWG wire
    • Connect common terminal to 0V/ground
  • Usage Precautions:
    • NPN sensors only — do not use PNP
    • Do not exceed 30VDC on any input
    • Use shielded cable in high-EMI areas
    • Do not leave inputs floating — wire all unused channels to a defined state
    • Verify common ground connection is solid before powering up
