  • Product Introduction: This is a 2-channel analog input module for the GE Fanuc 90-30 PLC platform. Unlike the ACC302 series, the ALG221 accepts voltage inputs (0-10V, 0-5V, 0-1V) as well as current inputs (0-20mA, 4-20mA). It provides 12-bit resolution (4096 counts) and is commonly used in applications where both voltage and current signals need to be read by the same module, such as mixed sensor environments in machine control and process monitoring.
Request Quote
Category: SKU: GE IC693ALG221

Description

 GE IC693ALG221

  • Technical Specifications:
    • Channels: 2 independent analog input channels
    • Input Type: Voltage (0-10V, 0-5V, 0-1V) or Current (0-20mA, 4-20mA) — software selectable
    • Resolution: 12-bit (4096 counts)
    • Accuracy: Plus or minus 0.2% of full scale
    • Linearity: Plus or minus 0.1% of full scale
    • Sampling Rate: 10 samples per second per channel
    • Isolation: 500V RMS channel-to-channel, 500V RMS channel-to-bus
    • Power Consumption: Approximately 1.5W
    • Operating Temperature: 0°C to 60°C
    • Input Impedance: 10 megohms (voltage mode), 250 ohms (current mode)
  • Functional Features:
    • 2 channels with individually configurable input type and range
    • Software-selectable between voltage and current modes
    • Diagnostic LED per channel
    • Backplane-powered
    • Compatible with GE Logicmaster 90-30 and CIMPLICITY
    • Supports both 2-wire and 4-wire connections
  • Application Scenarios:
    • Mixed-signal machine control (voltage sensors and current transmitters on same module)
    • Temperature monitoring with RTD and thermocouple transmitters
    • Pressure measurement with voltage-output transmitters
    • Level measurement in tanks
    • General-purpose analog data acquisition
  • Performance Parameters:
    • Common Mode Rejection: Greater than 90dB
    • Noise Rejection: Greater than 70dB normal mode
    • Bus Speed: Genius Bus, 10Mbps
    • MTBF: Greater than 150,000 hours
  • Material Composition:
    • Housing: UL94 V-0 ABS plastic
    • PCB: 4-layer FR-4, conformally coated
    • Connectors: Gold-plated backplane edge connector, screw terminals
    • Isolation: Opto-isolators per channel
  • Structural Features:
    • Standard IC693 module size (half-width compared to ACC302)
    • 2 green LED indicators on front panel
    • Screw-terminal field connections (18-22 AWG)
    • DIN-rail or chassis mount
  • Working Principle:
    • In voltage mode, the input signal is buffered and fed directly to a 12-bit ADC. In current mode, the signal passes through a 250 ohm shunt resistor to convert to voltage before ADC conversion. The digital value is stored in an internal register and read by the CPU via the Genius Bus. Optical isolation separates the field side from the logic side.
  • Installation Requirements:
    • Mount in IC693 or IC695 chassis
    • Use shielded twisted-pair cable
    • For voltage inputs, keep source impedance below 1k ohm for best accuracy
    • Ground shield at one end only
    • Keep analog cables away from digital I/O cables
  • Usage Precautions:
    • Do not exceed 10V on any voltage input channel
    • Do not exceed 24mA on any current input channel
    • Verify input range selection in software matches the actual field signal
    • For thermocouple inputs, use a separate cold junction compensation module (this module does not provide CJC)
    • Calibrate in software for best accuracy
