Description
GE IC695CPE305-AEAT
Technical Specifications
- Processor: Intel Atom E680 dual-core processor running at 1.6 GHz.
- User Memory: 5 MB of non-volatile user memory.
- Communication: Integrated Ethernet port and Serial port.
- I/O Capacity: Supports up to 128 I/O modules in a single chassis.
- Battery: Rechargeable supercapacitor for memory retention.
Functional Features
- High-Speed Processing: Executes Boolean logic in less than 0.11 milliseconds.
- Integrated Communications: Native Ethernet support for seamless HMI, SCADA, and peer-to-peer networking.
- Universal Backplane: Compatible with both traditional RX3i and high-speed CMM backplane modules.
- Redundancy Support: Fully compatible with RX3i redundant CPU and power supply configurations.
Application Scenarios
Large-scale manufacturing, water/wastewater treatment, oil & gas processing, and high-speed packaging lines requiring fast scan times and high I/O density.
Performance Parameters
- Scan Time: Sub-millisecond execution for basic instructions.
- Data Throughput: High-speed backplane communication via CMM modules.
- Memory Retention: Non-volatile memory ensures program retention without battery replacement.
Material Composition
Industrial-grade PCB with conformal coating, housed in a metal-reinforced plastic enclosure for EMI protection and thermal management.
Structural Characteristics
Standard RX3i CPU form factor with front-panel status LEDs, Ethernet/Serial ports, USB configuration port, and supercapacitor compartment.
Working Principle
Continuously scans input modules, executes user-programmed logic in a deterministic cycle, updates output modules, and manages communication tasks concurrently.
Installation Requirements
Mount in an RX3i chassis with adequate spacing for ventilation. Connect Ethernet cables using shielded CAT5e or better. Ensure proper chassis grounding.
Usage Precautions
Backup the program before firmware updates. Do not remove the CPU while power is applied. Verify firmware compatibility with existing I/O modules.
