Product Overview: The GE IC697ALG320 is an analog output module designed for the GE Fanuc Series 90-70 PLC system. It provides four individually configurable output channels that can be set to either voltage or current signals, supporting both unipolar and bipolar ranges. This module is commonly used in process control and machine automation where precise analog control is required, such as driving actuators, valves, or other field devices.

Request Quote
Category: SKU: GE IC697ALG320

Description

GE IC697ALG320

Technical Specifications:

  • Output Channels: 4
  • Output Types: Voltage and Current, individually configurable per channel
  • Voltage Ranges: 0 to 5V, 0 to 10V, ±5V, ±10V
  • Current Ranges: 0 to 20mA, 4 to 20mA
  • Resolution: 16-bit digital-to-analog conversion; 14-bit monotonicity
  • Update Rate: Fast, high-speed update across all channels
  • Isolation: Channel-to-channel and channel-to-backplane isolation
  • Terminal Block: Removable 40-pin front connector for field wiring
  • Power: 5V DC from backplane
  • Operating Temperature: 0°C to 60°C
  • Storage Temperature: -40°C to 85°C
  • Humidity: 5% to 95% non-condensing
  • Configuration: Software-configurable via programming software; no DIP switches or jumpers required
  • Calibration: Factory calibration stored in non-volatile EEPROM

Functional Features:

  • Per-channel selection of voltage or current mode and ranges, providing flexibility to interface with diverse field devices.
  • High-resolution 16-bit DAC with 14-bit monotonicity ensures smooth and accurate output signal generation.
  • Fast update rate allows quick response to changing control demands in high-speed applications.
  • Outputs are isolated from the backplane to protect against transients and ground loops.
  • Non-volatile memory retains configuration and calibration data without battery backup.
  • Software configuration simplifies setup and changes, reducing hardware handling.

Application Scenarios:

  • Process control systems for modulating control valves and variable-speed drives.
  • Manufacturing and packaging machinery requiring precise analog control.
  • Test and measurement equipment providing stimulus signals.
  • Energy management systems controlling setpoints and actuators.

Performance Parameters:

  • Output accuracy is maintained within tight tolerances for precise control.
  • Low drift and high stability across operating temperature range.
  • Compliant voltage/current outputs suitable for standard industrial loads.

Material and Structural Characteristics:

  • Industrial-grade PCB and components designed for longevity in harsh environments.
  • Robust front connector with screw terminals for secure field wiring.
  • Standard Series 90-70 single-slot module footprint.

Working Principle: The module receives digital values from the PLC CPU via the backplane bus. Each channel has a digital-to-analog converter (DAC) that transforms the digital data into a proportional analog voltage or current signal. The outputs are isolated to protect internal circuitry and improve noise immunity. Installation Requirements:

  • Install into any available slot in a Series 90-70 rack (IC697CHSxxx).
  • Use a compatible 40-pin removable terminal block for field wiring.
  • Ensure proper grounding of the rack and the field device shields to reduce noise.

Usage Notes:

  • Configure output ranges and modes using the programming software before operation.
  • Use shielded twisted-pair cables for analog signals to maintain signal integrity.
  • Verify load impedance compatibility with the selected output ranges to avoid errors.
  • Periodically check calibration if extreme precision is required.
