Description
GE IC697MDL653
Technical Specifications:
- Output Type: Discrete (on/off)
- Output Points: 32 points
- Voltage Rating: Typically 24V DC (verify specific datasheet for exact range)
- Current Rating: Per-point and per-module current limits as per datasheet
- Isolation: Group isolation between outputs and backplane
- Indicators: LED per point for status indication
- Terminal Block: Removable connector for field wiring
- Operating Temperature: 0°C to 60°C
- Humidity: 5% to 95% non-condensing
Functional Features:
- High-density 32-point design saves rack space.
- Per-point status LEDs simplify troubleshooting.
- Group isolation enhances protection and reduces noise coupling.
Application Scenarios:
- Controlling solenoid valves, motor starters, and indicator lights.
- Manufacturing and process automation requiring numerous discrete outputs.
Performance Parameters:
- Provides fast switching response for dynamic control.
- Maintains stable output under rated load conditions.
Material and Structural Characteristics:
- Industrial-grade PCB and components.
- Robust terminal block for secure wiring.
Working Principle: The module receives digital signals from the CPU and switches the corresponding output points on or off, controlling connected field devices. Installation Requirements:
- Install in any available slot in a Series 90-70 rack.
- Connect field devices to the terminal block following wiring diagrams.
- Ensure load voltage and current are within module ratings.
Usage Notes:
- Use appropriate protection devices such as fuses for inductive loads.
- Verify wiring polarity and connections before powering up.
