  • Product Introduction: This is a single-port 10/100 Mbps Ethernet communication module for the GE Fanuc 90-70 PLC. The “AA” suffix indicates a specific hardware/firmware revision, often related to connector type, compliance markings, or regional variants. It provides one RJ-45 Ethernet port with full TCP/IP stack support, enabling the 90-70 PLC to connect to SCADA systems, HMIs, and other Ethernet devices. It is a compact, cost-effective solution for Ethernet integration.
Request Quote
Category: SKU: GE IC698CPE010-AA

Description

 GE IC698CPE010-AA

  • Technical Specifications:
    • Ports: 1 x RJ-45 10/100Base-TX Ethernet
    • Speed: 10/100 Mbps auto-negotiation
    • Protocols: TCP/IP, UDP/IP, Modbus TCP, HTTP, FTP, SNMP v1/v2c, DHCP, DNS, EtherNet/IP (explicit messaging)
    • Max Connections: 32 simultaneous TCP/IP connections
    • Buffer Size: 32KB
    • Backplane Interface: IC698 90-70 backplane
    • Power Supply: 5VDC from backplane (300mA typical)
    • Operating Temperature: 0°C to 60°C
    • Dimensions: Standard IC698 module form factor
  • Functional Features:
    • Single Ethernet port with embedded TCP/IP stack
    • Web server for remote diagnostics
    • SNMP support for network management
    • Email alarm capability
    • LED indicators: Link (green), Activity (yellow), Fault (red)
    • Compatible with 90-70 programming software
  • Application Scenarios:
    • SCADA communication via Ethernet
    • Remote monitoring using web browser
    • Modbus TCP integration
    • Simple peer-to-peer messaging
    • Firmware updates via TFTP
  • Performance Parameters:
    • Throughput: Up to 60 Mbps (TCP)
    • Latency: <5ms local network
    • Isolation: Magnetic isolation (transformer) on Ethernet port
    • ESD Protection: ±8kV contact
    • EMC: EN 61131-2, FCC Part 15
  • Material Composition:
    • Housing: UL94 V-0 ABS
    • PCB: 4-layer FR-4, conformal coated
    • Connectors: RJ-45 magnetic jack, gold-plated backplane edge connector
    • Isolation: Pulse transformer
    • LEDs: Green, Yellow, Red
  • Structural Features:
    • Standard IC698 module size
    • 1 RJ-45 port on front panel
    • 3 LED indicators
    • DIN-rail mount
  • Working Principle:
    • CPU writes data to module’s dual-port RAM via 90-70 backplane. Ethernet controller encapsulates data into TCP/IP packets and transmits via RJ-45. Incoming packets are decapsulated and payload written to dual-port RAM for CPU access. Embedded web server runs on module’s internal processor.
  • Installation Requirements:
    • Mount in IC698 chassis
    • Connect Cat5e/Cat6 cable to RJ-45
    • Configure IP address in PLC software
    • Enable Ethernet port in CPU configuration
  • Usage Precautions:
    • Use shielded cable in high-EMI areas
    • Do not exceed 100m cable length
    • Set static IP or use DHCP consistently
    • Keep firmware updated for security
    • Do not expose web server to untrusted networks
