Description
GE IC755CSS12CDB-BG
Technical Specifications
- Part Number: IC755CSS12CDB-BG
- Display Size: 12-inch Active Matrix TFT LCD
- Resolution: 800 x 600 pixels (SVGA)
- Input Type: Resistive Touchscreen with Membrane Keypad overlay
Functional Features
- Graphical Visualization: Displays complex process animations, trending, and alarm management.
- Multi-Protocol Communication: Supports SNP, Modbus RTU/TCP, and various PLC communication protocols.
- Data Logging: Capable of storing historical process data and alarms locally.
Application Scenarios
Machine control panels, water/wastewater SCADA systems, and food processing automation.
Performance Parameters
- Brightness: High-intensity backlight for visibility in industrial lighting.
- Processor Speed: Fast rendering for responsive touch interactions.
Material Composition
Ruggedized NEMA 4X front bezel, industrial-grade LCD panel, and robust internal PCB.
Structural Characteristics
Panel-mount design with rear communication ports (RS-232, RS-485, Ethernet) and power terminals.
Working Principle
Communicates continuously with the connected PLC or controller, reading memory registers to update the graphical display and writing touch inputs back to the controller to execute commands.
Installation Requirements
- Cut out the appropriate panel opening and secure using provided mounting brackets.
- Connect communication and power cables according to the wiring diagram.
- Configure the communication protocol via the built-in setup menu.
Usage Precautions
- Clean the screen only with approved, non-abrasive cleaners.
- Ensure the power supply provides stable 24V DC.
- Avoid exposing the panel to direct sunlight or extreme heat.
