GE IS200AEADH1A
GE IS200AEADH1A - Image 2

GE IS200AEADH1A

Product Introduction:

  • The GE IS200AEADH1A is an analog input/output interface board used in GE Speedtronic Mark VI and Mark VIe turbine control systems. It interfaces with terminal boards to accept and condition a variety of analog signals, including LVDT inputs, servo valve outputs, thermocouple inputs, 4–20 mA inputs and outputs, vibration inputs, and generator/line signals. It works in coordination with STCA and TCQC boards for signal routing and processing.
Request Quote
Category: SKU: GE IS200AEADH1A

Description

GE IS200AEADH1A

  • Technical Specifications:
    • Series: GE Speedtronic Mark VI/Mark VIe
    • Signal Types Supported: LVDT, thermocouple, voltage inputs, 4–20 mA inputs and outputs, vibration inputs, pulse inputs, generator/line signals
    • Interface Connectors: 3PL data bus, JE connector for generator/line signals to TCQC, edge-mounted connectors
    • Operating Temperature Range: 0 °C to +60 °C
    • Relative Humidity: 5% to 95%, non-condensing
    • Power: Derived from the control rack via backplane connections
    • Dimensions: Standard Mark VI form factor (details per system drawings)
  • Functional Characteristics:
    • Conditions and scales numerous analog signals from terminal boards
    • Works with TCQC for generator and line signal exchange
    • Supports scaling and conditioning of 4–20 mA signals used in critical measurements such as compressor stall detection and fuel flow pressure
    • Provides signal routing to STCA via the 3PL data bus
    • Contains relays, transformers, capacitors, and support components for signal isolation and processing
  • Application Scenarios:
    • Gas turbine control systems where precise analog signal interfacing is critical
    • Steam turbine control for monitoring actuator positions, temperatures, and pressures
    • Generator excitation and control interfacing requiring high-fidelity signal processing
    • Power plant balance-of-plant (BOP) systems with extensive analog instrumentation
  • Performance Parameters:
    • High signal fidelity with low noise and drift
    • Fast response times essential for turbine control loops
    • Supports multiple signal types on a single board for compact system design
  • Material and Structural Characteristics:
    • Printed circuit board with industrial-grade components
    • Equipped with multiple plug-in and vertical connectors for board-to-board and field wiring
    • No front panel on the board; mounting facilitated by factory-drilled holes in corners
    • Includes hardware such as heat sinks and shielding to manage thermal and electrical performance
  • Working Principle:
    • Receives raw analog signals from terminal boards
    • Performs scaling, filtering, and isolation to produce conditioned signals
    • Communicates processed data to other boards (e.g., STCA, TCQC) via defined connectors
    • Converts control outputs to drive servo valves and other analog actuators
  • Installation Requirements:
    • Install into a Mark VI or Mark VIe control rack as per system manuals
    • Ensure all connectors are fully seated and locked
    • Verify alignment with terminal boards and backplane interfaces
    • Follow ESD handling procedures during installation and removal
  • Usage Notes:
    • Ensure compatibility with terminal board models and software versions
    • Regularly check connections for signs of wear or corrosion
    • Keep board areas clean and free from debris to avoid electrical faults
    • Refer to GE documentation for specific configuration and jumper settings
