GE IS200EGPAG1BCA
- Technical Specifications:
- Series: GE Mark IV/Mark VI
- Product Type: Microprocessor expansion board
- Operating Temperature Range: -35 °C to +65 °C
- Dimensions: Approximately 8.25 cm high × 4.15 cm (per Mark IV listings)
- Weight: Approximately 2 pounds
- Voltage: Compatible with system backplane voltages (typically 5 VDC logic levels)
- Interfaces: Compatible with system backplane connectors
- Functional Characteristics:
- Expands the I/O and processing capacity of the base controller
- Adds additional digital and analog channels for enhanced system capability
- Supports integration with existing Mark IV/Mark VI modules
- Provides a platform for custom logic and additional computational tasks
- Includes on-board components such as ASICs, memory, and interface logic
- Application Scenarios:
- Gas and steam turbine controls where extended I/O is required
- Excitation systems needing additional processing and interface capacity
- Retrofit projects upgrading existing turbine control systems
- Applications demanding additional custom logic within the control architecture
- Performance Parameters:
- Maintains compatibility with the timing and performance characteristics of the host system
- Supports reliable operation across the specified temperature range
- Provides deterministic response consistent with turbine control requirements
- Material and Structural Characteristics:
- Printed circuit board with industrial-grade components
- Mounting features compatible with Mark IV/Mark VI rack hardware
- Connector interfaces designed for reliable backplane connections
- Board layout optimized for thermal dissipation and signal integrity
- Working Principle:
- Interfaces with the host controller via the system backplane
- Executes additional logic and processing tasks as configured
- Provides expanded I/O interfacing to connect more sensors and actuators
- Communicates data and status to the main controller for coordinated operation
- Installation Requirements:
- Install into appropriate Mark IV/Mark VI rack slots ensuring proper alignment
- Secure mounting hardware to avoid mechanical stress on connectors
- Verify compatibility with the host controller firmware and configuration
- Follow manufacturer guidelines for grounding and shielding
- Usage Notes:
- Ensure proper configuration to avoid conflicts with main controller resources
- Monitor board status as part of routine system maintenance
- Replace only with compatible parts to maintain system integrity
- Handle with care to avoid mechanical damage and ESD exposure
