Description
GE IS200TBTCH1C
Technical Specifications
- Part Number: IS200TBTCH1C
- Manufacturer: General Electric
- Type: Turbine Terminal Board
- System Compatibility: Mark VI Speedtronic
Functional Features
- Field Wiring Interface: Provides secure, labeled termination points for turbine sensors and actuators.
- Signal Routing: Routes discrete, analog, and thermocouple signals to the I/O core.
- Isolation: Provides physical separation between field wiring and sensitive control electronics.
Application Scenarios
Gas and steam turbine sensor monitoring, valve actuator wiring, and auxiliary system integration.
Performance Parameters
- Signal Capacity: Supports multiple channels of discrete and analog I/O.
- Current/Voltage Rating: Rated for standard industrial control circuit loads.
Material Composition
High-quality screw or spring-clamp terminal blocks, robust PCB traces, and heavy-duty mounting hardware.
Structural Characteristics
Ruggedized board designed for DIN-rail or panel mounting, featuring clear terminal labeling and protective covers.
Working Principle
Acts as a passive or buffered junction point where field wires are terminated and internally routed to the backplane connector, bridging the gap between the physical turbine and the digital controller.
Installation Requirements
- Wire field devices strictly according to the GE terminal diagram.
- Torque all terminal screws to manufacturer specifications.
- Verify proper grounding of the terminal board shield.
Usage Precautions
- Never apply voltages exceeding the terminal board ratings.
- Ensure wire stripping length is correct to prevent short circuits.
- Verify all connections before energizing the control system.
