GE IS215ACLAH1A
Technical Specifications
- Series: Mark VIe
- Product Type: Analog Input Terminal Board
- Manufacturer: General Electric
Functional Features
- Analog Signal Interface: Supports 4-20mA, voltage, and RTD inputs.
- Signal Conditioning: Built-in filtering and protection circuits.
- Terminal Connectivity: Secure terminal blocks for field wiring.
Application Scenarios
- Turbine Control: Analog parameter monitoring in Mark VIe systems.
- Process Control: Field sensor integration.
Performance Parameters
- Signal Accuracy: High precision analog measurement.
- Noise Immunity: Excellent EMI/RFI rejection.
Material Composition
- Industrial-grade PCB with conformal coating.
Structural Characteristics
- Form Factor: Terminal board for rack mounting.
- Connectors: Backplane connectors for processor interface.
Working Principle
Receives analog signals from field devices, conditions them, and routes to the processor board via the backplane.
Installation Requirements
- Install in compatible Mark VIe rack.
- Use shielded cables for signal integrity.
Usage Precautions
- Handle with ESD precautions.
- Verify wiring polarity before power-up.
