Description
GE IS220PAICH1A 336A4940CSP3
- Technical Specifications:
- Series: GE Mark VI IS200
- Operating voltage: 27.4 VDC (minimum), 28.0 VDC nominal
- Channels: Multiple analog inputs and outputs (type depends on terminal board)
- Approvals: Hazardous location certifications (Class I, Zone 2, Group IIC; ATEX Zone 2, IIC; UL E207685, UL DEMKO 12 ATEX 1114875X)
- LED indicators: Four front-panel indicators for status
- Port: I/O port at the bottom of the unit
- Terminal board compatibility: Works with STAI series terminal boards
- Functional Features:
- High-precision analog signal conversion and conditioning
- Supports standard industrial analog signals (voltage, current, thermocouple, RTD, per terminal board capability)
- Ethernet-based integration with Mark VI controllers via IONet
- Diagnostics via LEDs and configuration tools
- Application Scenarios:
- Gas and steam turbine control systems
- Industrial process automation requiring reliable analog I/O
- Hazardous area applications in oil and gas, chemical plants
- Performance Parameters:
- Designed for fast and accurate signal conversion
- Supports high-channel density for cost-effective I/O
- Material and Structural Characteristics:
- Compact, rugged housing suitable for industrial environments
- Conformal coating for protection in harsh conditions
- Designed for mounting on compatible terminal boards
- Working Principle:
- Analog signals from field devices are conditioned and digitized by the pack, then transmitted over the IONet to Mark VI controllers. Output channels convert digital commands into analog signals to drive actuators.
- Installation Requirements:
- Mount on compatible STAI terminal boards
- Ensure proper 28 VDC power supply and grounding
- Configure using ToolboxST or GE configuration tools
- Usage Notes:
- Adhere to hazardous location installation requirements
- Verify certifications match local regulations
- Perform regular diagnostics and calibration as needed
