Description
GE P110-6052
Technical Specifications:
- Model: P110-6052
- Manufacturer: GE (Converteam)
- Series: CONVERTEAM P110
- Type: AC servo drive controller / advanced microcontroller
- Rated Power: 2.2 kW
- Rated Voltage: 400 V AC
- Rated Current: 5.5 A
- Rated Speed: 2000 RPM
- Control Method: Position, speed, and torque control
- Network Ports: 5 network ports
- Control Power: 18–36 V DC
- Cooling: Natural cooling (passive)
- Protection Rating: IP20
- Working Temperature: -40 °C to +85 °C
- Weight: Approximately 250 g
Functional Features:
- High-precision control: position accuracy ±0.1 μm, speed accuracy ±0.01%, torque accuracy ±0.1%
- Fast response time: less than 1 ms
- Overload capacity: 2 times rated torque
- Low noise operation
- Five network ports for rich connectivity options
- Supports multiple programming languages for flexible application development
- Modular design for easy integration into existing systems
- Industrial-grade design tolerating harsh environmental conditions
Application Scenarios:
- Robot control in manufacturing cells
- CNC machine tool axis drive control
- Packaging machinery motion control
- Printing machinery precision positioning
- Textile machinery synchronized motion control
- Production line control and process automation
- Marine propulsion and positioning systems
- Power generation auxiliary drive control
Performance Parameters:
- 2.2 kW rated power for medium-sized servo applications
- High-precision position, speed, and torque control loops
- Sub-millisecond response time for dynamic motion applications
- 2x overload capacity for demanding acceleration/deceleration profiles
- Five network ports enabling multi-axis synchronization and supervisory communication
Material and Structural Characteristics:
- Compact industrial-grade enclosure with integrated heat dissipation
- PCB with high-performance microprocessor and power semiconductor devices
- Terminal blocks for power, motor, encoder, and communication connections
- Natural convection cooling design without forced air
- Modular form factor for DIN-rail or panel mounting
Working Principle: The P110-6052 receives motion commands (position, speed, or torque setpoints) from a host controller via one of its five network ports. The internal microprocessor executes the control algorithm, comparing the setpoint with feedback from the motor encoder and adjusting the PWM output to the power stage. The power stage converts the 400 V AC input into precisely controlled three-phase voltage and current for the servo motor, achieving the commanded motion. Protection circuits monitor current, voltage, and temperature to safeguard the drive and motor. Installation Requirements:
- Mount in a control cabinet with adequate ventilation for natural cooling
- Connect 400 V AC power input and motor output cables per the wiring diagram
- Wire encoder feedback from the servo motor
- Connect 18–36 V DC control power
- Configure network addresses and communication parameters
- Set control mode (position, speed, or torque) via configuration software
Usage Notes:
- Verify motor voltage, current, and power ratings match the drive specifications
- Ensure proper shielding of encoder and communication cables to prevent EMI
- Configure control loop gains during commissioning for optimal performance
- Do not exceed the 2x overload rating for extended periods
- Confirm network port configuration matches the host controller communication protocol
- Periodically inspect cooling surfaces for dust accumulation
