Product Overview: The GE PCIE-5565PI0RC-100000 is a high-performance PCI Express network interface card designed for ultra-low-latency, deterministic data sharing. It creates a shared memory space across multiple computers, making it ideal for real-time control and simulation systems.

Request Quote
Category: SKU: GE PCIE-5565PI0RC-100000

Description

GE PCIE-5565PI0RC-100000 Technical Specifications:

  • Bus Interface: PCI Express (PCIe).
  • Network Speed: High-speed reflective memory network (up to 100 Mbps or higher).
  • Memory: On-board SRAM for local data storage and reflection.
  • Latency: Microsecond-level data transfer latency.

Functional Features:

  • Deterministic Data Transfer: Guarantees data delivery within a specified, predictable timeframe.
  • Automatic Reflection: Data written to one node is instantly and automatically mirrored to all other nodes on the network.
  • OS Support: Compatible with real-time operating systems like QNX, VxWorks, Linux, and Windows.
  • Redundancy: Supports redundant network paths for high availability.

Application Scenarios:

  • Hardware-in-the-loop (HIL) simulation and testing.
  • Redundant turbine control systems.
  • Multi-computer real-time data acquisition and synchronization.

Performance Parameters:

  • Latency: Sub-millisecond data propagation across the network.
  • Throughput: High-bandwidth data transfer suitable for large datasets.
  • Jitter: Extremely low network jitter for precise timing.

Material Composition & Structural Characteristics:

  • PCB: High-speed PCIe board with impedance-controlled traces.
  • Connectors: Standard PCIe edge connector and fiber optic or copper network ports.
  • Components: High-speed SRAM, network controller ASIC, and optical transceivers.

Working Principle: When a node writes data to its local reflective memory, the network controller broadcasts the data to all other nodes. Each receiving node writes the data to its identical memory location. This creates a globally consistent shared memory space accessible by all connected computers.

Installation Requirements:

  • Slot: Install in an available PCIe slot on the host computer.
  • Drivers: Install the appropriate operating system drivers and SDK.
  • Network: Connect nodes using fiber optic or copper cables in a ring, star, or daisy-chain topology.

Usage Precautions:

  • Compatibility: Verify OS and driver compatibility before deployment.
  • Cabling: Handle fiber optic cables with care to prevent signal loss.
  • Configuration: Configure network parameters (node ID, memory size) consistently across all nodes.
