Description
GE TED134150
Technical Specifications
- Manufacturer: General Electric (GE)
- Product Type: Control Relay / Contactor
- Series: GE Control Components
Functional Features
- Load Switching: Capable of switching high-current AC/DC loads.
- Mechanical Durability: High mechanical life rating for frequent operation.
- Auxiliary Contacts: Provides auxiliary contacts for control circuit feedback.
Application Scenarios
- Motor Control: Starting and stopping of industrial motors.
- Lighting Control: Switching of facility lighting circuits.
- Control Logic: Interlocking and sequencing in control panels.
Performance Parameters
- Contact Rating: Rated for specified voltage and current loads.
- Coil Voltage: Operates at standard control voltages (e.g., 24VDC, 120VAC).
Material Composition
- Silver-alloy contacts for arc resistance and long life.
- Thermoplastic housing for electrical insulation and mechanical protection.
Structural Characteristics
- Form Factor: Standard relay/contactor footprint.
- Mounting: Socket mount or direct panel mount.
Working Principle
When the coil is energized, a magnetic field pulls the armature, closing the main contacts to allow current flow to the load. Auxiliary contacts change state simultaneously for control feedback.
Installation Requirements
- Install in compatible socket or secure directly to panel.
- Ensure adequate clearance for arc flash and heat dissipation.
Usage Precautions
- Never exceed contact voltage or current ratings.
- Use proper wire crimps and torque specifications for connections.
