GE UR9EH

Product Overview The GE UR9EH is a control module designed for GE’s Multilin series of protection and control systems. It serves as an essential component in PLC automation equipment, providing enhanced input processing capabilities for complex industrial automation systems. The UR9EH is part of a family of modules that includes the UR9AH and UR9EV variants, each optimized for specific control functions.

Request Quote

Category: GE SKU: GE UR9EH

Description

GE UR9EH

Technical Specifications

Parameter	Specification
Function	Control Module with Enhanced Input Processing
System Compatibility	GE Multilin protection and control systems
Input Voltage	24V DC
I/O Capacity	Up to 128 digital inputs/outputs
Communication Ports	2 x Ethernet, 1 x Serial
Programming Languages	Ladder Logic, Function Block Diagram
Memory	512 KB RAM for program storage
Communication Protocols	Ethernet/IP, Modbus TCP
Durability Rating	IP65 for dust and water resistance
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)

Functional Features

Enhanced Input Processing: Optimized for high-speed digital input acquisition
Scalable Architecture: Supports expansion modules for growing system requirements
Multi-Protocol Communication: Ethernet/IP and Modbus TCP support for system integration
User-Friendly Interface: Intuitive programming and diagnostic capabilities
Robust Performance: Designed for harsh industrial environments
Real-Time Operation: Deterministic response for time-critical control applications
Diagnostic Functions: Built-in self-diagnostics and health monitoring

Structural Characteristics

Compact modular design for space-efficient installation
Rugged industrial-grade enclosure with IP65 protection
High-density I/O connectors for efficient wiring
LED status indicators for module health and I/O states
DIN rail mounting for quick installation
Conformal coated PCB for environmental protection

Working Principle The UR9EH module operates as a distributed I/O processor within the GE Multilin control architecture. It continuously scans digital input channels, processes the input states, and communicates the data to the main controller via Ethernet or serial communication links. The module’s internal processor executes the configured logic, applying input filtering and debounce as programmed. Output commands from the main controller are received and executed with deterministic timing. The module’s real-time operating system ensures consistent scan times and reliable control performance.
