Description
GE V7768-320000 Technical Specifications:
- Form Factor: VME64 SBC
- Processor: High-performance embedded processor
- Memory Architecture: SDRAM and non-volatile Flash storage
- Bus Standard: VME64
Functional Features:
- High-Performance Computing: Handles complex multitasking and real-time data processing.
- Extensive Memory: Large memory footprint for data-intensive applications.
- Broad OS Support: Compatible with major real-time operating systems.
- Ruggedized Design: Built to withstand vibration, shock, and temperature extremes.
Application Scenarios:
- Radar and sonar signal processing.
- Industrial automation and robotics control.
- Telecommunications infrastructure.
- Test and simulation systems.
Performance Parameters:
- Processing Speed: High clock speeds for rapid computation.
- I/O Bandwidth: High-speed VMEbus for minimal data latency.
Material Composition & Structural Characteristics:
- Construction: Multi-layer PCB with heavy copper planes for power distribution.
- Cooling: Conduction-cooled or convection-cooled variants available.
Working Principle: The board initializes via its bootloader, loads the OS, and begins executing application tasks. It acts as a VMEbus master, initiating read/write cycles to access memory and I/O modules across the backplane.
Installation Requirements:
- Backplane: Requires a VME64 backplane.
- Power: Stable VME power rails with adequate current capacity.
Usage Precautions:
- Handling: Use ESD-safe workstations and wrist straps.
- Cooling: Ensure chassis fans are operational before powering the board.
