ICS Triplex 9432

ICS Triplex 9432

Product Introduction: The 9432 is a high-integrity, high-density 16-channel isolated analogue input module designed explicitly for the ICS Triplex AADvance safety controller platform. This module converts real-time field data into stable variables for safety assessment, featuring comprehensive galvanic and photoelectric isolation on each channel to contain destructive field electrical spikes. The 9432 seamlessly scales across Simplex, Dual Redundant, or Triple Modular Redundant safety voting matrices.

Request Quote
Category:

Description

ICS Triplex 9432

Technical Specifications:

  • Channel Capacity: 16 fully isolated analog input channels
  • Input Voltage Range: 18-32 Vdc
  • Maximum Current: 260 mA
  • Power Consumption: 4.0 W
  • Heat Dissipation: 4.0 W (13.6 BTU/hr)
  • Input Current Range: 0-24 mA
  • Scan Time: 1.170 ms (Simplex), 1.965 ms (Dual), 2.656 ms (Triple)
  • Weight: 340 g (12 oz)
  • Dimensions: 4.2 x 12 x 16.5 cm
  • Operating Temperature: -40°C to +70°C
  • Relative Humidity: 10% to 95%, non-condensing

Functional Features:

  • 16 isolated analog input channels for high-density applications
  • Configurable in Simplex, Dual, or Triple redundancy
  • 5 configurable voltage bands per channel with 8 switching thresholds
  • Channel-to-channel isolation for improved signal integrity
  • Integrated field device and wiring diagnostics
  • Front-panel LED indicators for real-time status visibility
  • Seamless configuration via AADvance Workbench software
  • High-resolution sampling with excellent linearity
  • Supports HART pass-through for intelligent device management

Application Scenarios:

  • Power generation equipment monitoring
  • Oil and gas process variable tracking
  • Manufacturing process precision control
  • Chemical and pharmaceutical batch processing
  • Safety instrumented systems requiring high channel density

Performance Parameters:

  • TÜV Certified for IEC 61508 SIL 3 applications
  • Fast scan times ensuring real-time data acquisition
  • High accuracy with low temperature drift
  • 1500 Vrms isolation voltage
  • 350,000 hours mean time between failures
  • Strong anti-interference capability in harsh electrical environments

Material Composition:

  • Industrial-grade electronic components
  • Photoelectric isolation devices
  • High-precision ADC circuitry
  • Conformal coating for environmental protection
  • Durable industrial polymer housing

Structural Characteristics:

  • Compact high-density 16-channel design
  • Standard AADvance module form factor
  • Front-panel comprehensive LED indication
  • Lightweight construction at 340 grams
  • Compatible with T9832 dual termination assembly

Working Principle: The module processes 16 independent analog current signals through isolated channels. Each channel converts the 4-20 mA field signal into digital data using high-resolution ADCs. The isolation barriers protect against voltage transients and ground loops. Redundant configurations enable fault-tolerant operation where multiple channels vote on process values, eliminating single-point measurement errors.

Installation Requirements:

  • Install in T9300 I/O base unit
  • Mate with T9832 dual termination assembly for dual configurations
  • Ensure proper 24 VDC power supply
  • Configure redundancy mode via AADvance Workbench
  • Verify field wiring integrity before commissioning

Usage Precautions:

  • Do not exceed 32 VDC input voltage
  • Verify scan time requirements for application
  • Monitor LED indicators for channel fault detection
  • Maintain proper grounding practices
  • Follow ESD procedures during installation
  • Ensure termination assembly compatibility
