ICS Triplex TC‑303‑01‑2M0
Technical Specifications Cable finished length: 2.0 m; rated voltage: 300 V; operating temperature: ‑40 °C ~ +70 °C; overall copper‑braided shielding layer; multi‑group differential twisted‑pair conductors; metal‑shell locking‑type connectors; for static cabinet‑internal installation only.
Functional Features Original‑factory pre‑crimped connectors with fixed pin‑mapping; twisted‑pair‑structure suppresses signal‑crosstalk for short‑distance high‑speed‑signal transmission; compact‑size design fits dense‑layout cabinet‑internal wiring; reinforced strain‑relief structure resists cabinet‑vibration fatigue; mechanical‑lock‑latches prevent vibration‑triggered disconnection; full‑coverage‑shielding restrains cabinet‑internal electromagnetic interference.
Application Scenarios Short‑distance connection between adjacent‑slot Trusted‑system interface‑adapter modules; short‑span interconnection between I/O modules and matched FTA termination assemblies; compact‑layout SIS cabinet‑internal signal‑wiring; small‑and‑medium‑size ESD emergency‑shutdown‑system cabinet assembly.
Performance Parameters Shield‑coverage rate greater than 85 %; gold‑plated‑pin contact resistance less than 9 mΩ; insulation resistance above 1000 MΩ; connector‑mating‑life reaches 500 cycles; short‑distance‑signal‑transmission‑latency less than 0.5 ms; satisfies SIL 3‑system‑cabling‑performance‑indexes.
Material Composition Tinned stranded‑copper conductors, cross‑linked‑polyethylene‑insulation layers, copper‑braided‑shielding‑net, wear‑resistant‑PUR‑outer‑sheath, zinc‑alloy‑die‑cast‑metal‑connector‑housings, gold‑plated‑signal‑contact‑pins, injection‑molded‑rubber‑strain‑relief‑components.
Structural Characteristics Heavy‑duty‑rectangular‑metal‑shell‑connectors at both cable‑ends; signal‑groups adopt independent‑twisted‑pair‑layout; injection‑molded‑strain‑relief‑treatment at cable‑connector‑transition‑positions; pin‑out strictly complies with Trusted‑hardware‑port‑definitions.
Working Principle Transmits multi‑channel‑digital‑and‑analog‑safety‑signals between adjacent‑slot‑modules and termination‑assemblies. Twisted‑pair‑differential‑signal‑layout offsets electromagnetic‑induction‑noise. Continuous‑shielding‑layer diverts‑external‑interference‑to‑cabinet‑protective‑ground‑bar. Factory‑fixed‑pin‑assignment‑eliminates‑field‑wiring‑caused‑signal‑loop‑faults.
Installation Requirements Restrict‑usage‑to‑static‑installation‑inside‑temperature‑controlled‑control‑cabinets; static‑minimum‑bending‑radius‑equals‑ten‑times‑cable‑outer‑diameter;‑reserve‑slack‑length‑without‑tensile‑stress‑on‑cable‑conductors;‑lock‑connector‑mechanical‑latches‑after‑insertion;‑cable‑shield‑single‑end‑connects‑to‑cabinet‑protective‑ground‑bar;‑maintain‑physical‑separation‑from‑high‑power‑power‑cable‑bundles.
Usage Notes Forbid‑pulling‑cables‑by‑connector‑housings‑during‑handling;‑prevent‑sharp‑cabinet‑metal‑edges‑from‑scratching‑outer‑jacket;‑confirm‑full‑model‑compatibility‑before‑connector‑insertion;‑do‑not‑cut‑or‑re‑process‑factory‑terminated‑connectors;‑inspect‑pins‑for‑bending‑deformation‑before‑power‑on;‑avoid‑cabinet‑internal‑locations‑with‑oil‑mist‑and‑corrosive‑gas‑accumulation.
