ICS Triplex TC‑305‑01‑5M0
Technical Specifications Cable‑finished‑length:‑5.0 m;‑rated‑voltage:‑300 V;‑operating‑temperature‑range:‑‑40 °C‑~‑+70 °C;‑integral‑copper‑braided‑shielding‑layer;‑multi‑group‑differential‑twisted‑pair‑conductors;‑metal‑shell‑locking‑type‑connectors;‑limited‑to‑static‑cabinet‑internal‑installation‑only.
Functional Features Factory‑pre‑crimped‑connectors‑with‑fixed‑pin‑mapping;‑multi‑group‑differential‑twisted‑pairs‑suppress‑high‑speed‑bus‑signal‑crosstalk;‑enhanced‑strain‑relief‑structure‑improves‑anti‑vibration‑performance;‑mechanical‑locking‑latches‑prevent‑vibration‑caused‑connector‑loosening;‑full‑coverage‑shielding‑rejects‑cabinet‑internal‑electromagnetic‑interference;‑standard‑wire‑color‑coding‑facilitates‑maintenance‑and‑troubleshooting.
Application Scenarios Medium‑distance‑hot‑link‑interconnection‑between‑Trusted‑main‑controller‑chassis‑and‑T8300‑expander‑chassis;‑multi‑expander‑chassis‑cascading‑for‑large‑point‑count‑SIS‑systems;‑ESD‑emergency‑shutdown‑system‑inter‑chassis‑communication‑wiring;‑large‑petrochemical‑plant‑safety‑instrument‑system‑cabinet‑assembly.
Performance Parameters Shield‑coverage‑ratio‑greater‑than‑85 %;‑gold‑plated‑pin‑contact‑resistance‑less‑than‑9 mΩ;‑insulation‑resistance‑above‑1000 MΩ;‑connector‑mating‑life‑500‑cycles;‑signal‑transmission‑latency‑below‑1 ms;‑fully‑compliant‑with‑SIL 3‑system‑cabling‑specifications.
Material Composition Tinned‑stranded‑copper‑conductors,‑cross‑linked‑polyethylene‑insulation,‑copper‑braided‑shielding‑mesh,‑abrasion‑resistant‑PUR‑outer‑jacket,‑zinc‑alloy‑die‑cast‑metal‑connector‑housings,‑gold‑plated‑signal‑contact‑pins,‑injection‑molded‑rubber‑strain‑relief‑components.
Structural Characteristics Heavy‑duty‑rectangular‑metal‑shell‑connectors‑at‑both‑cable‑ends;‑triplicated‑bus‑signal‑groups‑adopt‑independent‑twisted‑pair‑layout;‑injection‑molded‑strain‑relief‑treatment‑at‑cable‑connector‑transition‑sections;‑pin‑out‑strictly‑matches‑Trusted‑hot‑link‑bus‑hardware‑definitions.
Working Principle Transmits‑triplicated‑high‑speed‑Inter‑Module‑Bus‑signals‑between‑main‑chassis‑and‑expander‑chassis‑interface‑adapters.‑Twisted‑pair‑differential‑signal‑technology‑offsets‑electromagnetic‑induction‑noise.‑Continuous‑shielding‑layer‑diverts‑external‑interference‑to‑cabinet‑protective‑ground‑bar.‑Factory‑fixed‑pin‑assignment‑eliminates‑field‑wiring‑caused‑bus‑signal‑fault‑risks.
Installation Requirements Only‑for‑static‑installation‑inside‑temperature‑controlled‑control‑cabinets;‑static‑minimum‑bending‑radius‑equals‑ten‑times‑cable‑outer‑diameter;‑reserve‑slack‑length‑without‑tensile‑force‑on‑cable‑conductors;‑fasten‑connector‑mechanical‑locking‑latches‑after‑insertion;‑cable‑shield‑layer‑single‑end‑connects‑to‑cabinet‑protective‑ground‑bar;‑maintain‑adequate‑physical‑separation‑from‑high‑power‑power‑cable‑bundles.
Usage Notes Never‑pull‑cables‑by‑connector‑housings‑during‑handling;‑prevent‑sharp‑cabinet‑metal‑edges‑from‑damaging‑outer‑jacket;‑verify‑full‑model‑matching‑before‑connector‑insertion;‑prohibit‑cutting‑or‑re‑processing‑factory‑terminated‑connectors;‑inspect‑pins‑for‑bending‑or‑deformation‑before‑power‑on;‑avoid‑cabinet‑internal‑zones‑with‑oil‑mist‑and‑corrosive‑gas‑accumulation.
