Kollmorgen AKM11ESSMN2-03

Kollmorgen AKM11ESSMN2-03

Product Introduction: The AKM11ESSMN2-03 is a compact synchronous servo motor from the Kollmorgen AKM1 series, the smallest frame size in the AKM family. This motor is designed for light-load, high-speed applications where space constraints and low inertia are critical. The ESSMN2 configuration indicates SFD feedback, M-type connector, no brake, and a specific shaft and seal arrangement, with a -03 revision suffix indicating a custom or application-specific variant.

Request Quote
Category:

Description

Kollmorgen AKM11ESSMN2-03

Technical Specifications:

  • Frame Size: AKM1 (40mm flange diameter)
  • Stack Length: 1 (shortest stack)
  • Winding Type: E winding
  • Feedback Device: SFD (Smart Feedback Device)
  • Connector Type: M (0.5m shielded cable with IP20 connector)
  • Brake: N (no brake)
  • Shaft: 2 (specific shaft configuration)
  • Seal: 03 (specific seal variant)
  • Max Rated DC Bus Voltage: 320 VDC
  • Max Rated Speed: 8000 RPM
  • Insulation Class: F (155°C)
  • Protection Rating: IP54 (standard)
  • Certifications: CE, cURus, UL

Functional Features:

  • Ultra-compact 40mm frame size for space-constrained applications
  • Highest speed capability in the AKM family at 8000 RPM
  • Low rotor inertia for fast dynamic response
  • SFD feedback for precise position control
  • Low cogging torque for smooth operation
  • Plug-and-play compatibility with AKD series drives
  • Ideal for high-speed, light-load positioning tasks

Application Scenarios:

  • Small robot joint actuators
  • High-speed pick-and-place systems
  • Semiconductor wafer handling
  • Laboratory automation equipment
  • Precision positioning stages
  • Medical device actuators
  • Textile machinery high-speed feed systems

Performance Parameters:

  • Continuous Torque (Stall): Within AKM1 frame range, up to 0.409 Nm
  • Peak Torque: Within AKM1 frame range, up to 1.46 Nm
  • Max Rated Power: Up to 0.30 kW at max bus voltage
  • Max Rated Speed: 8000 RPM
  • Rotor Inertia: Very low, optimized for fast acceleration

Material Composition:

  • Silicon steel laminated stator core
  • NdFeB permanent magnet rotor
  • Aluminum alloy housing
  • Class F insulation winding
  • Miniature precision ball bearings

Structural Features: The AKM1 frame is the most compact in the AKM family with a 40mm diameter flange. The short stack length 1 configuration minimizes the axial dimension while the E winding provides a balanced torque-speed characteristic. The M-type connector provides a compact IP20-rated cable interface suitable for clean indoor environments.

Working Principle: The motor operates as a three-phase PMSM with the same fundamental electromagnetic principles as larger AKM motors. The compact design features a smaller stator bore and shorter stack, resulting in lower torque but significantly reduced rotor inertia. This enables extremely fast acceleration and deceleration, making it ideal for high-speed, light-load applications.

Installation Requirements:

  • Mount using standard AKM1 flange mounting pattern
  • Ensure the mounting structure accommodates the compact 40mm frame
  • Use appropriately sized cables for the M-type IP20 connector
  • Provide adequate ventilation despite the compact size
  • Connect SFD feedback to a compatible drive input

Usage Precautions:

  • Do not exceed the rated continuous torque for the AKM1 frame
  • Monitor motor temperature during high-speed continuous operation
  • The IP20 connector is not suitable for wet or dusty environments
  • Use Kollmorgen WorkBench software for motor parameter configuration
  • Verify the drive supports the 320 VDC bus voltage of the frame
  • Handle with care due to the compact and lightweight construction
