Description
Kollmorgen controller CD‑CD‑5230‑R6ES‑CR06561
Technical Specifications: Single‑phase 120‑240 VAC input; continuous output current 5 Arms; peak output current 10 Arms; switching frequency 8 kHz; support SFD, EnDat and incremental encoder feedback; ±10 V analog command, pulse‑direction command; optically‑isolated digital IO channels; RS232 service port; operating temperature 0 ℃‑50 ℃; storage temperature ‑20 ℃‑85 ℃; protection rating IP20.
Functional Features: Digital torque‑velocity‑position three‑loop closed‑loop control; SFD motor auto‑recognition; electronic gear function; encoder emulation output; loop parameter auto‑tuning; hardware fault latch; external limit, home and enable signal processing; fault relay output.
Application Scenarios: Vintage packaging machinery, textile production equipment, import‑made fixture equipment, industrial automation spare‑part replacement.
Performance Parameters: Maximum pulse‑command frequency 1 MHz; I²T thermal overload protection; hardware protection for over‑current, DC‑bus over‑voltage, DC‑bus under‑voltage, over‑temperature and feedback‑signal loss.
Material Composition: Die‑cast aluminum alloy housing; IGBT power modules; gold‑plated industrial connectors; flame‑retardant PCB circuit board; integrated metal heat‑sink fins; built‑in cooling fan.
Structural Features: Standard DIN‑rail book‑style housing; front‑panel LED status indicator lights; DIN‑rail locking clip on rear side; power terminals, feedback connectors and IO terminals on rear section; forced‑air cooling by internal fan.
Working Principle: Input AC power is rectified to DC‑bus voltage. Power inverter outputs three‑phase AC current for servo‑motor driving. Motor feedback signal is converted into digital quantity for closed‑loop algorithm processing. Drive executes motion commands from analog input or pulse‑direction input. Hardware monitoring circuits detect abnormal conditions and shut down power‑stage output when fault occurs.
Installation Requirements: Vertically mount on DIN‑35 rail inside control cabinet; maintain 25 mm upper‑lower ventilation clearance and 10 mm left‑right clearance; separate power‑cable and signal‑cable wiring paths; connect protective‑earth terminal to cabinet grounding bar reliably; maintain cabinet IP20 protection level.
Usage Notes: Live disassembly of wiring terminals is forbidden; wait for DC‑bus full discharge before maintenance work; ambient operating temperature shall not exceed 50 ℃; spare‑part replacement must verify motor feedback type and firmware‑version compatibility.
