Kollmorgen MT308B1-E2C1

Kollmorgen MT308B1-E2C1

Product Introduction
The MT308B1-E2C1 is a motor drive module manufactured by Kollmorgen, designed to deliver high performance and reliability in industrial automation applications. It provides precise control over motor operations and is suitable for use in manufacturing environments, robotics, and machinery requiring accurate motion control. The module is certified to meet CE and RoHS standards, ensuring environmental compliance and safety in industrial settings.

Request Quote
Category:

Description

Kollmorgen MT308B1-E2C1

Technical Specifications

  • Operating Voltage: 220V AC
  • Output Frequency: Up to 30kHz
  • Certifications: CE, RoHS
  • Series: MT308B1-E2C1
  • Order Number: MT308B1-E2C1

Functional Features

  • High Efficiency: Delivers efficient power delivery to motors under demanding operating conditions
  • Robust Performance: Designed for reliable operation in industrial environments with precise motor control
  • Certified Compliance: Meets CE and RoHS environmental and safety standards
  • Custom Processing Support: Supports custom configuration options to meet specific customer requirements

Application Scenarios

  • Manufacturing: Precision motor control in production machinery
  • Robotics: Servo motor drive for robotic arm joints and actuators
  • Industrial Automation: General-purpose motor drive in automated equipment
  • Machinery: Equipment requiring precise and reliable motor operation

Performance Parameters

  • Output Frequency Range: Up to 30kHz for smooth motor operation
  • Voltage Stability: Stable operation at 220V AC rated voltage

Material Composition
Industrial-grade electronic components housed in a robust enclosure designed for control cabinet or panel mounting in demanding industrial environments.

Structural Features
Compact modular design with standardized connectors for power input, motor output, and control signals. The module is engineered for straightforward integration into existing automation systems.

Working Principle
The drive module receives control commands from a host controller and converts the input AC voltage into precisely regulated power output at frequencies up to 30kHz. The internal power electronics regulate voltage and frequency to achieve accurate motor speed and torque control, while built-in protection circuits safeguard against overcurrent and overtemperature conditions.

Installation Requirements

  • Install in a control cabinet with adequate ventilation
  • Connect to a 220V AC power supply matching the rated voltage
  • Ensure proper grounding of the module chassis
  • Connect motor and control signal cables according to the wiring diagram

Usage Notes

  • Verify input voltage matches the 220V AC specification before powering on
  • Monitor module temperature during continuous high-load operation
  • Use the diagnostic interface to check for fault codes during commissioning
  • Ensure motor parameters are correctly configured for optimal performance
