Description
Kollmorgen S403-M
- Technical Specifications:
- Series: ServoStar 400 (S400)
- Type: Digital servo amplifier
- Control Modes: Torque, velocity, and position control
- Feedback Resolution: Supports high-resolution feedback devices
- Functional Features:
- Multi-mode servo control (torque, speed, position)
- Electronic gear and cam functionality
- Compatible with Kollmorgen AKM and other brushless servo motors
- Integrated fault protection (overcurrent, overvoltage, overtemperature)
- Application Scenarios:
- Industrial automation and production lines
- Packaging and logistics systems
- Machine tools and processing equipment
- Medical equipment and laboratory automation
- Performance Parameters:
- Current loop bandwidth: 3–5 kHz
- High speed response frequency for rapid command tracking
- 24-bit high-resolution feedback support
- Material Composition:
- Industrial-grade housing with thermal management features
- IGBT power modules for efficient switching
- Structural Features:
- Compact module-style form factor
- Standard Molex and RJ45 (SynqNet) interfaces
- Working Principle:
- The drive processes motion commands through embedded digital control loops (current, velocity, position), continuously adjusting the PWM output to the motor based on real-time feedback from encoders or resolvers.
- Installation Requirements:
- Panel or control room mounting
- Proper cable shielding and grounding for EMC compliance
- Adequate ventilation for thermal management
- Usage Notes:
- Ensure motor nameplate parameters are correctly configured in the drive
- Check feedback cable integrity if encoder faults occur
- This is a legacy product; verify spare parts availability
